Latest Technologies of Renesas Electronics America

2022-12-09, ISL3259E±15kV ESD protection, 100Mbps, 5V, PROFIBUS, completely fail-safe, RS-485/RS-422 Transmitter and receiver

The ISL3259E is a ±15kV IEC61000 ESD Protected, 5V powered, single transceiver that meets both the RS-485 and RS-422 standards for balanced communication. It also features the larger output voltage and higher data rate (up to 100Mbps) required by high speed PROFIBUS applications. The low bus currents (+220µA/-150µA) present a 1/5 unit load to the RS-485 bus.

2022-12-06, Dual channel differential DSL line driver

The EL1528 is a dual channel differential amplifier designed for driving full rate ADSL signals at very low power dissipation. The high drive capability of 450mA makes this driver ideal for both CAP and DMT designs. It contains two pairs of wideband, high-voltage, current mode feedback amplifiers optimized for low power consumption in DSL systems

2022-12-06, Renesas offers low noise/low power /2 line bus single digital control potentiometer

The X9429 integrates a single digitally controlled potentiometer (XDCP) on a monolithic CMOS integrated circuit. The digital control potentiometer is realized by series array of 63 resistance elements. Between each element are tap points connected to the wiper terminal by a switch. The user controls the position of the wiper on the array through the 2-wire bus interface

2022-12-05, Renesas offers Precision Low Power FGA Voltage

The ISL60002 FGA voltage references are very high precision analog voltage references fabricated using the Renesas proprietary Floating Gate Analog (FGA) technology and feature low supp

2022-12-05, Renesas 40MHz Non-Inverting Quad CMOS Driver

The EL7457 is a high speed, non-inverting, quad CMOS driver. It is capable of running at clock rates up to 40MHz and features 2A peak drive capability and a nominal on-resistance of just 3. The EL7457 is ideal for driving highly capacitive loads, such as storage and vertical clocks in CCD applications. It is also well suited to ATE pin driving, level-shifting, and clock-driving applications.

2022-12-02, Renesas provides a horizontal output synchronous separator EL1883ISZ-T7

The EL1883 video synchronous separator is manufactured using Elantec's high-performance analog CMOS process. The device extracts synchronous timing information from standard and non-standard video inputs and Macrovision pulses. It offers composite synchronization, vertical synchronization, burst/back porch timing, and horizontal output. Fixed 70mV Sync hint slice provides sync edge detection when the video input level is between 0.5VP-P and 2VP-P (sync hint amplitude 143mV to 572mV).

2022-12-01, Combined with innovative circuit design technology IDT71V416

The IDT71V416 is a 4,194,304 bit high-speed static RAM, organized at 256K x 16. It is manufactured using IDT's high-performance, highly reliable CMOS technology. Packaged in a 44-pin, 400 mil plastic SOJ and a 44-pin, 400 mil TSOP Type II package and 48-ball mesh array in a 9mm x 9mm package

2022-11-30, Extension to Ringing SLIC series developed by Renesas Electronics

RSLIC18 series ring subscriber line interface circuit (RSLIC) supports analog ordinary telephone service (POTS) and is suitable for short and medium loop length, wireless and wired applications. This series of products are very suitable for remote user units, providing designers with the flexibility of high ringing voltage and low power consumption system requirements.

2022-11-29, Renesas Electronics provides RTKA271082DE0000BU evaluation board

Renesas Electronics RTKA271082DE0000BU Evaluation Board is configured to evaluate the operation of the RAA271082 Automotive PMIC. The RAA271082 offers three synchronous buck regulators and one low dropout linear regulator.

2022-11-19, Renesas Electronics introduces a family of automotive radar transceivers with superior accuracy and power consumption

Renesas Electronics launched a new 4x4 channel, 76-81GHz radar transceiver RAA270205 to enter the automotive radar market. Designed to meet the demanding requirements of ADAS (Advanced Driver Assistance System) and L3 and higher level autonomous driving applications. Renesas has added the transceiver to its growing portfolio of sensor fusion products, including radar, vision systems and other sensing units, drawing on years of automotive expertise working with customers around the world.

2022-11-03, The new power management IC introduced by Renesa that meets ASIL B standard is an ideal choice for car camera applications

Renesas Electronics, a global supplier of semiconductor solutions, announced the launch of the RAA271082, an innovative vehicle-scale power management IC (PMIC) for next-generation in-vehicle camera applications. The RAA271082 is an ISO-26262 compliant multi-function multi-output power supply IC containing a primary high voltage synchronous step-down regulator, two secondary low voltage synchronous step-down regulators and a low voltage LDO regulator.

2022-10-29, Renesa ISL95866 PWM regulator

Renesas's ISL95866 provides a complete power solution for desktop microprocessors that support core (IA), graphics (GT), or unsliced graphics (GTUS or GTX). The controller provides control and protection for two voltage regulators (VRS). The first VR can be configured to operate in 4-, 3-, 2- or 1 phase. The second VR can be configured to operate in 3-, 2-, or 1- phases. VRs have programmable SVID addresses that allow maximum flexibility when supporting desktop processor SKUs.

2022-10-06, The ClockMatrix system synchronizer provides Class D compliance for O-RAN S-Plane

Renesas Electronics Corporation's 8A34001 System Synchronizer for IEEE 1588 is employed within the AMD Zynq UltraScale+ RFSoC DFE ZCU670 Evaluation Kit and reference design for 5G NR.

2022-10-05, Introduction of IDE for ECU class cars hardware - free software development for ECU class cars

Renesas Electronics Corporation has launched a new IDE that swiftly enables engineers to create software for automotive ECUs containing multiple hardware devices. The fully integrated environment supports co-simulation, debug and trace, high-speed simulation, and distributed processing software over multiple SoCs and MCUs – all without the requirement for actual hardware.

2022-09-30, Renesas Electronics Releases RZ/V Series Devices with Built-in Vision AI Accelerator for Accurate Image Recognition and Multi-Camera Image Support

Renesas Electronics announced the launch of a new RZ/V2MA device capable of processing image data from multiple cameras, further expanding its RZ/V family of microprocessors (MPU) product line and bringing a new level of high-precision image recognition to vision AI applications.

2022-09-29, Renesas Electronics Introduces ClockMatrix System Synchronizer

Renesas Electronics Introduces ClockMatrix System Synchronizer, Achieves Class D Compliance for O-RAN S-Plane Requirements, ClockMatrix Device Provides Synchronization and Software Solutions for AMD RFSoC DFE Development Platform and O-RU Reference Design

2022-09-28, Renesas' high-performance ASSP features an Arm Cortex-R52 processor with FPU

2022-09-26, Renesas' family of optocouplers uses 3.3 V/5 V power supply
