Latest Technologies of STMicroelectronics

2024-11-18, TDA7560 Amplifier: Introduction, Pinout and Features

The TDA7560 is a high-performance Class AB audio power amplifier built using advanced BCD (Bipolar, CMOS, DMOS) technology.

2024-11-07, UA741CN Operational Amplifier: Pinout, Schematic Diagram and Applications

The UA741CN is a high-performance monolithic operational amplifier built on a single silicon chip, designed for a broad spectrum of analog applications. It features a high gain and operates across a wide range of voltages, making it exceptionally suitable for use in integrators, summing amplifiers, and general feedback circuits.

2024-10-21, BDW93C Transistor: Basics, Pinout and Specification

2024-10-10, TEA2025B Monolithic IC: Working Principle, Pinout and Alternatives

The TEA2025B is a versatile monolithic IC housed in a 12+2+2 Powerdip package, specifically for use as a dual or bridge power audio amplifier.

2024-10-07, L9637D Monolithic IC: Introduction, Pinout and Specification

The L9637D is a monolithic integrated circuit, supporting the ISO 9141 standard for efficient communication between vehicles and diagnostic tools.

2024-09-30, TDA7379 Amplifier: Pinout, Circuits and Applications

The TDA7379 is an automotive audio amplifier for car audio systems. It can provide high output power, typically achieving 4×45W, making it suitable for driving various speaker configurations.

2024-08-27, TDA2822M Audio Amplifier: Test Circuit, Pinout and Features

The TDA2822M is a dual low-power audio amplifier integrated circuit (IC) commonly used in portable audio devices and low-power amplifier applications. It can operate with a low voltage supply, typically between 3V and 15V. The TDA2822M can drive both stereo (dual-channel) and bridge-tied load (BTL) configurations, allowing it to deliver output power up to 1W per channel in BTL mode.

2024-08-14, TDA7377 Audio Amplifier: Pinout, Circuit and Features

The TDA7377 is a high-performance audio amplifier IC for automotive and other high-power audio applications. It operates as a bridge amplifier, capable of driving speakers with a total output power of up to 14 watts per channel.

2024-07-29, TL084CN Operational Amplifier: Pinout, Circuits & Features[FAQs]

The TL084CN is a high-performance operational amplifier with low noise, high slew rate, and wide bandwidth. It provides precise analog signal processing and excels in applications that require minimal distortion and high fidelity, such as audio amplification and active filtering.

2024-07-17, BU406 NPN Transistor: Working Principle, Pinout and Alternatives

The BU406 is a versatile NPN power transistor with a maximum collector current rating of 4A and a collector-emitter voltage rating of 60V, suitable for handling medium power levels. The BU406 has excellent thermal performance and is easy to install.

2024-06-20, Transistor Pinout, Circuit and Applications [FAQs]

The 2SC5200 is a high-power NPN transistor commonly used in audio amplifiers and other high-power applications.The 2SC5200 can handle a maximum collector current of 15A and a maximum collector-emitter voltage of 230V.

2024-06-18, L200CV Pinout, Specifications and Features

The L200CV is a versatile voltage regulator that can be used for both positive and negative voltage regulation. It can be adjusted to provide an output voltage ranging from 2.85V to 36V with a maximum output current of 2A. The L200CV is commonly used in power supplies and other applications requiring a stable and adjustable voltage output.

2024-06-14, LM334Z Principle, Pinout and Applications

The LM334Z is a three-terminal adjustable current source. Like the LM134 and LM234, its current output is determined by an external resistor and no other external components are required. The LM334Z can provide a current output from 1 µA to 10 mA by adjusting the external resistor between the pin and the negative supply pin.

2024-03-19, SiC-Based Traction Inverters: Revolutionizing Electric Mobility

In the current age of electric mobility, there is a crucial need for power electronics that are both efficient and high-performing. Traction inverters are crucial components in electric vehicles (EVs) as they are responsible for transforming DC power from the battery into AC power to operate the electric motor.

2024-02-01, STMicroelectronics introduces controllers that make portable products look amazing

As the flagship product of the STM32 series of high performance and low power consumption, the STM32U5 continues the application range of the STM32F2/F4/F7, while having lower energy consumption and higher cost performance. In industrial control systems, U5 can undertake core functions such as master controller, system monitoring and graphic display.

2024-01-26, ZINSIGHT Boosts Efficiency in EV E-Compressor Controllers with STMicroelectronics’ SiC

STMicroelectronics has just announced an agreement to supply its 3rd generation silicon-carbide (SiC) planar MOSFETs for the e-compressor controllers from ZINSIGHT Technology, a Chinese high-tech company specializing in SiC power modules and advanced electric power conversion systems, used in “new energy vehicles” (NEVs), also dubbed EVs or BEVs outside China.

2024-01-08, Intelligent circuit breaker development preferred SCR: ultra-small size, support 750V surge peak voltage

The X0115ML is ST's first off-state surge peak voltage 750V compact thyristor (SCR) for Ground Fault Circuit Breakers (GFCI) and arc Fault Circuit Breakers (AFCI). The SOT23-3L micropackage (2.75mm x 3.10mm) is probably the smallest thyristor on the market today. Engineers can save a lot of board space while allowing industrial applications to have 600V off-state repeat peak voltages

2023-12-26, STMicroelectronics Unifies AI Toolchain Across Product Lines

STMicroelectronics (ST) has unified its tinyML development toolchains into a single stack, ST Edge AI Suite, which will cater for all ST hardware going forward, including ST’s microcontrollers, microprocessors and ML-enabled MEMS sensors.
