Latest Technologies of Intersil

Records 43

Page 1/3

2023-04-13, Dual channel synchronous step-down PWM controller

The ISL6228 IC is a dual channel synchronous step-down PWM controller with Intersil's Robust Ripple Regulator (R3) technology to provide truly superior dynamic response to input voltage and output load transients. The integrated MOSFET driver and guide diode result in fewer components and a smaller implementation area.
2023-04-12, Dual power/low power /1024 point /SPI bus, single digital control potentiometer

The X9110 integrates a single digital control potentiometer (XDCP) on a single chip CMOS integrated circuit. The digital control potentiometer is realized by a series array of 1023 resistance elements. XDCP can be used as a three-terminal potentiometer or a two-end variable resistor for a variety of applications including control, parameter adjustment, and signal processing.
2023-04-11, A high frequency MOSFET driver designed to drive up and down power

The PX3511A and PX3511B are high frequency MOSFET drivers specifically designed to drive upper and lower power N-Channel MOSFETs in a synchronous rectified buck converter topology. These drivers combined with the ISL6595 Digital Multi-Phase Buck PWM controller and N-Channel MOSFETs form a complete core-voltage regulator solution for advanced microprocessors.
2023-04-03, 2MHz, Super Helicopter stabilized operational amplifier

The ICL7650S Super Chopper Stabilized amplifier provides extremely low input bias voltage and is extremely stable in terms of time and temperature. It is a direct replacement for the industry standard ICL7650, offering improved input bias voltage, lower input bias voltage temperature coefficient, lower input bias current, and wider common-mode voltage range. In addition, the ICL7650S internally compensates for unit gain operation.
2023-04-03, 1 microsecond precision sampling and holding amplifier

The HA-5320 is designed for use in precision, high-speed data acquisition systems. The circuit consists of an input transconductance amplifier, a low leakage analog switch and an output integrated amplifier, which can provide high current charging. The monolithic device is manufactured using an Intersil dielectric isolation process that minimizes stray capacitance and eliminates SCRS.
2023-03-30, 64 point, 2-wire serial bus dual digital control potentiometer

The X9221A integrates two digitally controlled potentiometers (XDCPS) on a single chip CMOS integrated microcircuit. The digital control potentiometer is realized by a series array of 63 resistance elements. XDCP can be used as a three-terminal potentiometer or a two-end variable resistor for a variety of applications including control, parameter adjustment, and signal processing.
2023-03-16, 4 Channel video and audio controller for secure applications

The TW2837 features four high-quality NTSC/PAL video decoders, two-color display controllers, and dual video encoders, and includes four built-in analog anti-aliasing filters, four 10-bit ADC converters, proprietary digital gain/clamp controllers, high-quality Y/C separators to reduce cross noise and a high-performance free zoom. The TW2837 contains two video encoders and three 10-bit digital-to-analog converters to provide two composite or s videos, and also includes audio codecs with four audio ADC and one ADC.
2023-02-15, Low noise/low power /SPI bus

The X9410 integrates two digitally controlled potentiometers (XDCPS) on a monolithic CMOS integrated circuit. The digital control potentiometer is realized by a series array of 63 resistance elements. XDCP can be used as a three-terminal potentiometer or a two-end variable resistor for a variety of applications including control, parameter adjustment, and signal processing.
2023-02-11, 8 character, microprocessor compatible, LED display decoder driver

The ICM7243 is an 8-character, alphanumeric display driver and controller which provides all the circuitry required to interface a microprocessor or digital system to a 14-segment or 16-segment display. It is primarily intended for use in microprocessor systems, where it minimizes hardware and software overhead. Incorporated on-chip are a 64-character ASClI decoder, 8x6 memory, high power character and segment drivers, and the multiplex scan circuitry
2023-01-14, Intersil offers General Purpose Timers

The ICM7555 and ICM7556 are CMOS RC timers providing significantly improved performance over the standard SE/NE 555/556 and 355 timers, while at the same time being direct replacements for those devices in most applications. Improved parameters include low supply current, wide operating supply voltage range, low Threshold, Trigger and Reset currents, no crowbarring of the supply current during output transitions, higher frequency performance and no requirement to decouple Control Voltage for stable operation.
2023-01-09, CD/MP3 quality stereo 2:1 multiplexer with click-and-pop elimination

The Intersil ISL54405 is a single supply, bidirectional, dual single-pole/double-throw (SPDT) ultra low distortion, high OFF-Isolation analog switch that can pass analog signals that are positive and negative with respect to ground. It is primarily targeted at consumer and professional audio switching applications such as computer sound cards and home theater products.
2023-01-07, Hybrid digital dual pwm controller

The ISL6367 is a Hybrid Digital dual PWM controller and is designed to be compliant to Intel VR12/IMVP7 specifications. Its 6- phase PWMs control the microprocessor core or memory voltage regulator, while its single-phase PWM controls the peripheral voltage regulator for graphics, system agent, or processor I/O. It includes programmable functions and telemetries for easy use, high system flexibility and overclocking applications using SMBus, PMBus, or I2 C (Modified) interface, which is designed to be conflict free with CPU’s SVID bus
2022-12-27, Renesas four-way digital control potentiometer

The X9241A integrates four digitally controlled potentiometers (XDCPS) on a monolithic CMOS integrated microcircuit.
2022-12-21, Single power/low power /256 point /SPI bus single digital control potentiometer

The X9271 integrates a digitally controlled potentiometer (XDCP™) on a monolithic CMOS integrated circuit. The digital control potentiometer is realized by a series array of 255 resistance elements. Between each element are contacts connected to the wiper terminal by a switch.
2022-12-14, Multiphase PWM controller is provided

The ISL6244 provides core-voltage regulation by driving 2 to 4 interleaved synchronous-rectified buck-converter channels in parallel. Interleaving the channel timing results in increased ripple frequency which reduces input and output ripple currents. The reduction in ripple results in lower component cost, reduced dissipation, and a smaller implementation area.
2022-10-21, Intersil ISL8215M single channel dc - dc step-down power supply module

Intersil's ISL8215M power module is a single channel synchronous step-down complete power supply capable of providing up to 15 a of continuous current. The working range of ISL8215M is from a single 7V to 42V wide input power rail, integrating controller, power inductor and mosfet, which is optimized for space constrained and battery powered applications.
2022-03-30, Custom designed fuel cell and fuse tester

Intepro Systems offers a complete suite of testing services for the battery and semiconductor industries, including batteries and battery testers up to 2MW, as well as battery simulators for research and Oems in EV, aerospace and other industries. The company's integrated test system uses the latest regenerative technology to deliver up to 95 percent of the energy output throughout the test process, reducing overall energy costs. Products available include bi-directional DC power supply and 1.9MW automatic ranging source, programmable AC power supply and 2MW regenerative power supply
2022-02-19, The world's first industrial grade 112-layer 3D TLC SSD

Innodisk has launched the world's first 112-tier 3D TLC SOLID-state drives. The new TLC SSD family marks the continued evolution of the company's 3D NAND design, providing greater efficiency, faster performance, and increased capacity. The new 112-tier PCIe Gen 4X4 series expands capacity to U.2 SSD 8TB and M.2 (P80) 4TB. There are other improvements necessary to adapt to the needs of the industrial and Iot markets
